2023 VERMEER 504R Premium Baler The Vermeer 504R Premium baler is fully loaded and comes standard with a silage kit specially designed for high output of high-moisture crops. This package offers more capacity in heavy crops and produces good looking bales in tough conditions. Silage or not, this is your first-class baler. Drivetrain Bearing And Sprocket Configuration-Round drive shafts and bearings Roller Chains-Single 60 and 80 Torque Protection Pickup-Radial pin clutch Driveline-540 rpm, extended lube, friction clutch Operational Net Tension Control-via mechanical adjustment Density Readings-Physical gauge Bale Density Adjustments-Standard manual through hydraulic relief valve Moisture-Standard - up to 27% Field Statistics-10 fields Display-4.3 in (10.9 cm) color touch screen Control System Type-Atlas™ control system Pickup Lift-Hydraulic Flotation-Gauge wheels 4.8-16 HD semi-pneumatic with spring assist Stripper Bands-Steel Teeth Spacing-2.83 in (7.2 cm) Number Of Teeth-(60) double steel coil Tooth Bars-5 Width Tooth To Tooth-60 in (152.4 cm) Pickup Type-Camless wide Pto Horsepower Recommended-65 hp (48.5 kw) Pto Horsepower Minimum-55 hp (41 kw) Type Of Lace-Alligator rivet or no laces (endless belts) Length Of Belt Short-455.5 in (1157 cm) Length Of Belt Long-465.5 in (1182.4 cm) Width Of Belt-6.8 in (17.3 cm) Number Of Belts-6 Belt Type-Premium mini rough top or endless Start Roller Size-4.5 in (11.4 cm) Idler Roller Size-3.5 in (8.9 cm) Drive Roller Size-4.78 in (12.1 cm) Maximum Bale Weight-2000 lbs (907.2 kg) Bale Width-47 in (119.4 cm) Bale Diameter-36 in - 60 in (91.4 cm - 152.4 cm) Silage Kit-Standard 3 Year Pickup Warranty-Standard Bale Shape Indicators-Standard Bales Per Hour-Standard Twine System-Optional Netwrap System-Standard Extra Roll Storage-Standard Dimensions- Height-111 in (281.9 cm) Weight Fully Optioned-5460 lbs (2476.6 kg) Tires-Standard - 31 x 13.5-5; Optional - 480-45 R17 flotation tire Width With Standard Tires-100 in (254 cm) Length With Ramp-169 in (429.3 cm) Length With Net-173 in (439.4 cm) Length Standard-156 in (396.2 cm)
