MINCON HAMMERS

Mincon’s DTH (down-the-hole) hammers are engineered to deliver outstanding drilling performance across all applications while reducing energy consumption through the optimal use of available air. From construction and quarrying to mining and well drilling, their DTH hammers provide unmatched efficiency, reliability, and longevity.
LEARN MORE

HDD30 Pilot Hammer

  • Bit size: 3.5″
  • Hammer diameter: 3.03″
  • Hammer length: 66.4″
  • Vermeer Drill Rig: D8x12, D10x15 (S3)
  • Rig application: Up to 4,535 kg

HDD40 Pilot Hammer

  • Bit size: 4.5″
  • Hammer diameter: 3.54″
  • Hammer length: 73.5″
  • Vermeer Drill Rig: D20x22 (S3)
  • Rig application: Up to 9,100 kg

HDD50 Pilot Hammer

  • Bit size: 5.25″
  • Hammer diameter: 4.06″, 4.25″
    103mm wearsleeve,
    108mm sonde housing
  • Hammer length: 79″
  • Vermeer Drill Rig: D23x30 (S3), D24x40 (S3), D40x55 (S3)
  • Rig application: Up to 10,900 – 18,150 kg

HDD60 Pilot Hammer

  • Bit size: 6.25″
  • Hammer diameter: 5″
  • Hammer length: 81″
  • Vermeer Drill Rig: D40x55 (S3), D60x90 (S3), D100x120 (S2), D100x140 (S3)
  • Rig application: Up to 18,150 – 45,400kg

HDD70 Pilot Hammer

  • Bit size: 7.25″
  • Hammer diameter: 5.75″
  • Hammer length: 82.6″
  • Vermeer Drill Rig: D60x90 (S3), D100x120 (S2), D100x140 (S3), D130S, D130x150
  • Rig application: 45,400kg – 68,000kg

HDD70PR Pull Reamer

  • Bit options: 7″, 8″, 9″
  • Rig application: 9,100kg – 18,150kg
  • Hammer length: 51.2″

HDD80PR Pull Reamer

  • Bit options: 10″, 12″, 14″, 16″, 18″
  • Rig application: 10,900kg – 22,700kg
  • Hammer length: 61″
